Meet the Nest x Yale Lock
The lock that works for you.
Meet the Nest x Yale Lock
The lock that works for you.
The Nest x Yale lock is made for people. Most locks are made for keys.
The Nest x Yale lock is made for people.
With the Nest x Yale Lock, we created a tamper-proof, key-free deadbolt that connects directly with the Nest app. Now, you can lock and unlock your door from anywhere. Give people you trust a passcode, instead of a key. And always know who comes and goes.
With the Nest x Yale Lock, we created a tamper-proof, key-free deadbolt that connects directly with the Nest app. Now, you can lock and unlock your door from anywhere. Give people you trust a passcode, instead of a key. And always know who comes and goes.
Just say "Hey Google, lock the door".
The Nest x Yale Lock can replace your existing deadbolt on standard doors, 1-3/4" to 2-1/4" thick, with just a screwdriver. Your door can be any width or height.
The Nest x Yale Lock can replace your existing deadbolt on standard doors, 1-3/4" to 2-1/4" thick, with just a screwdriver. Your door can be any width or height.
Hardware
Nest x Yale Lock
Nest Connect
Bundled with Nest Connect
Includes
Strike Plate
Mounting Screws
4 AA alkaline batteries
Install guide
Installation Guide with removable door template
Quick Start Card
The Nest x Yale Lock replaces most common deadbolt locks and will fit several standard doors that are between 1-3/8" and 2-1/4" thick. Only the thickness and *Backset will matter. Your door can be any width or height.
The bore hole for the deadbolt must be 2-1/8" with a backset* of 2-3/8" or 2-3/4" and an edge bore hole of 1".
The Nest x Yale Lock will work with wood, metal, and fiberglass doors. However, it will not be compatible with glass doors, sliding doors, mortise locks, or multi-point locks.
*Backset is the distance between the edge of your door and the center of your deadbolt's hole. ie. If your deadbolt center is more than 2 3/4" (70mm) away from the edge of your door, it will not be compatible. You can refer to the installation guide for additional information.
The Nest x Yale Lock is a secure and battery powered lock that does not utilize your home's Wi-Fi network to lock and unlock your door using the keypad. The lock uses 4 standard AA alkaline batteries. With standard usage, your lock will last for approximately 1 year and will start receiving low battery warnings around 5 weeks before full depletion.
When your Nest door lock runs low on battery, you will receive a notification on your phone via the Nest App, where you will also be able to check the lock's battery status. You will also be able to see a red low battery light on your keypad when in use. Once your battery reaches critically low levels, you will be notified again before it is completely depleted. if your battery dies, you won't be locked out completely. Take a 9v alkaline battery and hold at the terminals at the bottom of your lock to provide temporary power. You can then re-enter your passcode and unlock the door.
The Nest x Yale Lock is simple to install. View our installation guide and videos for details.
Nest x Yale Lock is a smart lock by ASSA ABLOY that pairs to a Google Account and uses Google services to connect to the internet. Google, Nest, Google Nest Audio and related marks and logos are trademarks of Google LLC.
1 - For set up and full feature access including remote control, mobile alerts, and software updates, Nest x Yale Lock requires the Nest Connect and a working internet connection over Wi-Fi, the free Nest app, and an active Google Account.
2 - Voice control with Google Assistant requires a compatible smart device (sold separately).
